Yuneec H520E drone kit with E90x camera
In a set
PROFESSIONAL APPLICATIONS KIT
The Hexacopter H520E was developed specifically for commercial drone applications and provides SAR ground teams, surveyors, police, firefighters and surveying teams with a versatile tool. The H520E is a robust, powerful and flexible UAV platform that can be perfectly customized to meet individual requirements, thus enabling a variety of industry applications. Long flight times and high-quality camera systems with built-in GPS data allow for fast and precise area capture, while the interference-free precision compass enables flying even in previously difficult-to-fly environments. In addition to performance and flexibility, great emphasis was placed on the safety of the drone's flight and data when developing the platform.
KEY FEATURES OF YUNEEC H520E
- New powerful flight control processor
- New battery connector with fail-safe design
- New long range OFDM module
- Designed for professional, commercial and government requirements
- High-precision, low-noise compass
- New 30-pin payload interface
- No need to transfer data to external servers
- Stable and secure 6 rotor system
- Energy efficient and quiet operation
- ST16E controller with integrated 7" touchscreen display, voice output and comprehensive DataPilot™ software
- HDMI signal directly from the ST16E for displaying live video from the drone on larger monitors
- Mission planning on a computer or ST16E
KEY FEATURES OF YUNEEC E90X
- 20 megapixels / 4K at 60 frames per second
- 1" CMOS sensor
- Up to 8x digital zoom
- Low distortion 23mm wide angle lens
- 30-pin X connector
- 320° gimbal rotation for superior image stabilization
- Ideal for professional film and photo shoots, 3D mapping/modeling and search and rescue applications
Box Contents:
- H520E Hexacopter with OFDM module
- E90x camera
- 2 Batteries 4S-6200mAh
- EU charger
- 12v charging cable
- ST16E controller (touch screen)
- 1 ST16E battery
- USB charging cable
- Sun shield Screen protector
- Neck strap
- SD card
- User manual
SPECIFICATION
DRONE:
- Weight: 1856g (without camera)
- Maximum flight time: Up to 25 min
- Max. Flight Height: 5000 meters (MSL)
- Battery: 4S 6200mAh Li Ion
- Motors: 730kV
- Diagonal length: 520 mm
- Max. Climb Speed: 4 m/s
- Max. Descent Speed: 2.5 m/s
- Operating Temperature: 0°C - 40°C
- Storage Temperature: 10°C - 50°C
- Sensor: Ultrasonic sensor
- REMOTE CONTROL:
- Operating System: Android™
- Number of Channels: 16
- Transmission Distance Range (optimal conditions): 4km (Europe) / 6km (FCC)
- Frequency Band: 2.4 GHz, 5.8
- Video Link Resolution: HD 720p
E90X Camera Specifications
- Weight: 300g
- Operating Temperature: -10°C - 40°C
- Angular Vibration Range: ±0.02°
- Connector: X Connector
- Max. Angular Speed: Tilt:30°/s, Pan:120°/s
- Gimbal Working Range: Tilt +30°－120°, Pan 330°
- Sensor: CMOS 1 inch / 20MP
- Lens: Viewing angle 91° F/2.8, Focal length - equivalent 23mm
- Photo Resolution: 3:2 (5472 x 3648); 4:3 (4864 x 3648); 16:9 (5472 x 3080)
- Video Resolution: H.264 4096×2160(24/25/30/48/50/60p) 3840×2160(24/25/30/48/50/60p) 2720×1530(24/25/30/48/50/60p) 1920×1080(24/25/30/48/50/60/120p) 1280x720(24/25/30/48/50/60/120p)
- Photo Formats: JPG, JPEG + DNG (lossless - raw)
- Video Format: MP4
- Shutter Modes: Single, Burst
- Exposure Modes: Auto, Manual
- Exposure Compensation: ±3.0
- Metering Modes: Spot, Center, Average
- Shutter Speeds: 4--1/8000s
- White Balance: Auto, Tungsten, Sunrise, Sunset, Sunny, Cloudy, Fluorescent lighting, Lock
- ISO Range: 100 - 6400
