DJI Mavic 3 Multispectral - Capture more data, work more efficiently
To conduct effective aerial surveys, you need to see what is invisible. That's why the Mavic 3 Multispectral offers two forms of vision. It combines an RGB camera with a multispectral camera to scan and analyze crop growth, ensuring complete transparency. Managing agricultural production requires precision and data, and the Mavic 3M meets both conditions.
Highly integrated imaging system
The newly upgraded imaging system with a single 20 MP RGB camera and four 5 MP multispectral cameras (green, red, red edge, and near-infrared bands). It is suitable for applications such as precise aerial surveys, crop growth monitoring, and natural resource studies.
5 MP multispectral sensors
Four multispectral cameras - green, red, red edge, and near-infrared bands.
Sunlight sensor
The built-in sensor captures solar radiation and records it in the image file, allowing for light alignment during 2D reconstruction. As a result, you can enjoy more accurate NDVI results, as well as greater precision and consistency in data collected over time.
Precise images that capture every pixel
The Mavic 3M is equipped with an RTK module, which provides centimeter-level positioning accuracy. The flight control system, camera, and RTK module synchronize within microseconds to precisely determine the imaging center position of each camera. This allows the Mavic 3M to perform accurate aerial surveys without the use of ground control points.
Batteries optimized for efficiency
A flight time of up to 43 minutes allows for covering more area during each mission, enabling coverage of up to 200 hectares.
Convenient charging
Fast battery charging with a 100W HUB charger or direct drone charging using 88W fast charging.
Stable signal, smooth image transmission
The O3 system integrates two transmission signals and four reception signals, providing a transmission range of up to 8 km.
Omnidirectional obstacle detection
The drone is equipped with a range of vision sensors with a wide field of view, precisely detecting obstacles in all directions and enabling smooth avoidance. Moreover, the Mavic 3M allows for easy terrain-following measurements in areas with steep slopes.
Orchard mapping
The Mavic 3M enables terrain-following aerial surveys in orchards - even on sloping terrain. You can also use it in conjunction with DJI Terra or DJI SmartFarm Platform to reconstruct high-resolution maps and take advantage of automatic tree identification, distinguishing trees from other objects, and generating 3D operational routes for agricultural drones. All of this translates into greater safety and work efficiency.
Variable fertilizer and pesticide dosing planning
Fertilizing rice, regulating cotton growth, or spraying potatoes with foliar fertilizers - in each of these cases, the DJI Mavic 3M will allow you to obtain multispectral images of crops. You can then use DJI Terra or DJI SmartFarm Platform to create NDVI maps and other vegetation indices, capturing differences in crop potential and generating recommendation maps that enable agricultural drones to dose selected substances variably. All of this allows users to reduce costs, increase yields, and protect the environment.
Intelligent field reconnaissance
The Mavic 3M can conduct automatic field reconnaissance and transmit field observation images to the DJI SmartFarm Platform in real-time via the 4G network. It enables quick detection of abnormalities such as crop gaps, weed density, or lodging. It also allows for intelligent analyses, such as seedling identification for cotton and rice production testing. The drone uses artificial intelligence to provide real-time information on crop growth, facilitate agronomic decision-making, and enable the seamless management of up to 70 hectares of land by a single person.
Environmental and natural resource monitoring
The Mavic 3M is also useful for environmental and natural resource studies, such as monitoring water enrichment or checking forest distribution, urban green spaces, and more.
Package contents
- Mavic 3 Multispectral drone
- RTK module
- DJI Care Enterprise Basic for 1 year
- DJI SmartFarm Platform
- DJI Terra software for 3 months
- 1x drone battery
- DJI RC Pro Enterprise controller
- USB-C power adapter
- 2x USB-C cable
- Power cable
- Camera cover
- 3x pairs of spare propellers
- Hex wrench
- 64GB memory card
- Carrying case
DRONE | |
---|---|
Net weight (with propellers and RTK module) [1] | 951 g |
Maximum takeoff weight | 1050 g |
Dimensions | Folded (without propellers): 223×96.3×122.2 mm (length × width × height) Unfolded (without propellers): 347.5×283×139.6 mm (length × width × height) |
Diagonal | 380.1 mm |
Maximum ascent speed | 6 m/s (Normal Mode) 8 m/s (Sport Mode) |
Maximum descent speed | 6 m/s (S Mode) 6 m/s (N Mode) |
Max flight speed (no wind) | 15 m/s (N Mode) Forward: 21 m/s, Sideways: 20 m/s, Backward: 19 m/s (S Mode)[2] |
Max wind speed resistance | 12 m/s[3] |
Max takeoff altitude | 6000 m (without payload) |
Max flight time (no wind) | up to 43 minutes[4] |
Max hover time (no wind) | up to 37 minutes |
Maximum flight distance | up to 32 km (CE)[4] |
Maximum tilt angle | 30° (N Mode) 35° (S Mode) |
Maximum angular velocity | 200°/s |
GNSS | GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when the RTK module is enabled) |
Hover accuracy | Vertical: ±0.1 m (with vision system); ±0.5 m (with GNSS); ±0.1 m (with RTK) Horizontal: ±0.3 m (with vision system); ±0.5 m (with high-precision positioning system); ±0.1 m (with RTK) |
Operating temperature range | -10° to 40° C |
Internal storage | None |
Motor model | 2008 |
Propeller model | 9453F - Enterprise |
Light sensor | Built into the drone |
RGB CAMERA | |
Image sensor | 4/3 CMOS Effective pixels: 20 MP |
ISO range | 100-6400 |
Shutter speed | Electronic shutter: 8-1/8000 s Mechanical shutter: 8-1/2000 s |
Maximum image size | 5280×3956 |
Shooting mode | Single shot: 20 MP Timelapse: 20 MP JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s JPEG + RAW: 3/5/7/10/15/20/30/60 s Panorama: 20 MP (original material) |
Video resolution | H.264: 4K: 3840×2160@30fps FHD: 1920×1080@30fps |
Maximum video transmission speed | 4K: 130Mbps FHD: 70Mbps |
Supported file system | exFAT |
Image format | JPEG/DNG (RAW) |
Video format | MP4 (MPEG-4 AVC/H.264) |
MULTISPECTRAL CAMERA | |
Image sensor | 1/2.8-inch CMOS, Effective pixels: 5 MP |
Lens | FOV: 73.91° (61.2° x 48.10°) Equivalent focal length: 25 mm Aperture: f/2.0 Focus: Fixed focus |
Multispectral camera band | Green (G): 560 ± 16 nm; Red (R): 650 ± 16 nm; Red Edge (RE): 730 ± 16 nm; Near Infrared (NIR): 860 ± 26 nm; |
Gain range | 1x-32x |
Shutter speed | Shutter speed |
Maximum image size | 2592×1944 |
Image format | TIFF |
Video format | MP4 (MPEG-4 AVC/H.264) |
Shooting mode | Single shot: 5 MP Timelapse: 5 MP TIFF: 2/3/5/7/10/15/20/30/60 s |
Video resolution | H.264 FHD: 1920 x 1080@30fps Video content: NDVI/GNDVI/NDRE |
Maximum video transmission speed | Stream: 60 Mbps |
SENSOR SYSTEM | |
Sensor system type | Omnidirectional dual-sensor vision system, with an infrared sensor at the bottom of the drone |
Forward | Distance measurement range: 0.5 m to 20 m Detection range: 0.5 m to 200 m Effective obstacle avoidance speed: Flight speed ≤15 m/s FOV: Horizontal 90°, vertical 103° |
Backward | Distance measurement range: 0.5 m to 16 m Effective obstacle avoidance speed: Flight speed ≤12 m/s FOV: Horizontal 90°, vertical 103° |
Sideways | Distance measurement range: 0.5 m to 25 m Effective obstacle avoidance speed: Flight speed ≤15 m/s FOV: Horizontal 90°, vertical 85° |
Upward | Distance measurement range: 0.2 m to 10 m Effective obstacle avoidance speed: Flight speed ≤6 m/s FOV: Front and rear 100°, left and right 90° |
Downward | Distance measurement range: 0.3 m to 18 m Effective obstacle avoidance speed: Flight speed ≤6 m/s FOV: Front and rear 130°, left and right 160° |
Operating environment | Front, back, left, right, up: Surfaces with distinct patterns and adequate lighting (> 15 lux, environments with normal indoor fluorescent lighting) Below: Surfaces with diffuse reflective material and reflectivity >20% (such as walls, trees, people, etc.); Adequate lighting (>15 lux, environments with normal exposure to indoor fluorescent light) |
GIMBAL | |
Stabilization system | 3-axis mechanical gimbal (tilt, roll, pan) |
Mechanical range | Tilt: -135° to 45° Roll: -45° to 45° Pan: -27° to 27° |
Controlled range | Tilt: -90° to 35° Pan: Uncontrolled |
Max control speed (tilt) | 100°/s |
Angular vibration range | ±0.007° |
VIDEO TRANSMISSION | |
Video transmission system | DJI O3 Image Transmission Industry Edition |
Live View quality | Remote control: 1080p/30fps |
Operating frequency | 2.400-2.4835 GHz 5.725-5.850 GHz |
Maximum effective signal distance (unobstructed, no interference) | CE: 8 km SRRC: 8 km MIC: 8 km |
Maximum transmission distance (with obstacles) | Strong interference (urban landscapes, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC) Moderate interference (suburban landscapes, urban parks, etc.): 3-6 km (CE/SRRC/MIC) Weak Interference (remote fields, open farmlands, etc.): 6-8 km (CE/SRRC/MIC) |
Maximum download speed | 15 MB/s (with DJI RC Pro Enterprise Edition) |
Latency (depending on environment and mobile device) | Around 200 milliseconds |
Antennas | 4 antennas, 2 transmitters, and 4 receivers |
Transmitter power (EIRP) | 2.4 GHz: <20 dBm (CE/SRRC/MIC) 5.8 GHz: <30 dBm (SRRC), <14 dBm (CE) |
Others | Supports DJI Cellular module |
BATTERY | |
Capacity | 5000 mAh |
Standard voltage | 15.4 V |
Maximum charging voltage | 17.6 V |
Cell type | LiPo 4S |
Cell chemistry | Lithium Cobalt |
Energy | 77 watt-hours |
Weight | 335.5 g |
Charging temperature | 5° to 40° C |
STORAGE | |
Supported microSD cards | Drone: Please use a memory card with a V30 speed rating or higher, or use a memory card from the recommended list |
Recommended microSD cards | Remote control: SanDisk Extreme PRO 64GB V30 A2 microSDXC SanDisk High Endurance 64GB V30 microSDXC SanDisk Extreme 128GB V30 A2 microSDXC SanDisk Extreme 256GB V30 A2 microSDXC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 667x 64GB V30 A2 microSDXC Lexar High-Endurance 64GB V30 microSDXC Lexar High-Endurance 128GB V30 microSDXC Lexar 667x 256GB V30 A2 microSDXC Lexar 512GB V30 A2 microSDXC Samsung EVO Plus 64GB V30 microSDXC Samsung EVO Plus 128GB V30 microSDXC Samsung EVO Plus 256GB V30 microSDXC Samsung EVO Plus 512GB V30 microSDXC Kingston Canvas Go! Plus 128GB V30 A2 microSDXC Kingston Canvas React Plus 128GB V90 A1 microSDXC Drone: SanDisk Extreme 32GB V30 A1 microSDHC SanDisk Extreme PRO 32GB V30 A1 microSDHC SanDisk Extreme 512GB V30 A2 microSDXC Lexar 1066x 64GB V30 A2 microSDXC Kingston Canvas Go! Plus 64GB V30 A2 microSDXC Kingston Canvas React Plus 64GB V90 A1 microSDXC Kingston Canvas Go! Plus 128GB V30 A2 microSDXC Kingston Canvas React Plus 128GB V90 A1 microSDXC Kingston Canvas React Plus 256GB V90 A2 microSDXC Samsung PRO Plus 256GB V30 A2 microSDXC |
BATTERY CHARGER | |
Input | 100V to 240V (AC), 50Hz to 60Hz, 2.5A |
Output power | 100 W |
Output | Maximum output power 100 W (total) When both ports are used, the maximum output power of a single interface is 82 W, and the charger will dynamically allocate the output power of the two interfaces depending on the load power. |
CHARGING HUB | |
Input | USB-C: 5V to 20V, 5.0A |
Output | Battery port: 12V to 17.6V, 8.0A |
Rated power | 100 W |
Charging type | 3 batteries charged one by one |
Charging temperature | 5° to 40° C |
RTK MODULE | |
Dimensions | 50.2 × 40.2 × 66.2 mm |
Weight | 24±2 g |
Interface | USB-C |
Power | approx. 1.2 W |
RTK positioning accuracy | RTK Fix: Horizontal: 1 cm + 1 ppm; Vertical: 1.5 cm + 1 ppm |
DJI RC ENTERPRISE EDITION | |
Image transmission system | DJI O3 Image Transmission Industry Edition |
Maximum effective signal distance (unobstructed, no interference [8] | CE: 8 km SRRC: 8 km MIC: 8 km |
Image transmission frequency band [7] | 2.400-2.4835 GHz 5.725-5.850 GHz |
Antennas | 4 antennas, 2 transmitters and 4 receivers |
Image transmission frequency band and transmitter power (EIRP) | 2.4 GHz: <20 dBm (CE/SRRC/MIC) 5.8 GHz: <14 dBm (CE); <23 dBm (SRRC) |
Wi-Fi protocol | 802.11 a/b/g/n/ac/ax Support 2×2 MIMO Wi-Fi |
Wi-Fi operating frequency [7] | 2.400-2.4835 GHz 5.150-5.250 GHz 5.725-5.850 GHz |
Wi-Fi operating frequency and transmitter power (EIRP) | 2.4 GHz: <20 dBm (CE/SRRC/MIC) 5.1 GHz: <23 dBm (CE/SRRC/MIC) 5.8 GHz: <14 dBm (CE) |
Bluetooth protocol | Bluetooth 5.1 |
Bluetooth operating frequency | 2.400-2.4835 GHz |
Bluetooth transmitter power (EIRP) | <10 dBm |
Screen resolution | 1920×1080 |
Screen size | 5.5 inches |
Screen refresh rate | 60 fps |
Screen brightness | 1,000 nits |
Touch screen | 10-point multi-touch |
Battery | Lithium-ion battery (5000 mAh, 7.2 V) |
Charging type | It is recommended to use a 100W battery charging hub or a USB charger with a 12V or 15V specification |
Rated power | 12 Watts |
Storage capacity | Internal memory (ROM): 64 GB Supports microSD cards to increase storage capacity |
Charging time | About 1.5 hours (measurement made using only a 100W battery charging hub for charging the controller or using a 15V USB charger) About 2 hours (measurement made using a 12V USB charger) About 2 hours and 50 minutes (measurement made using a 100W battery charging hub for simultaneous charging of the aircraft and controller) |
Operating time | About 3 hours |
Video output port | Mini-HDMI port |
Operating temperature | -10° to 40° C |
Storage temperature range | <1 month: -30° to 60° C One to three months: -30° to 45° C Three to six months: -30° to 35° C More than six months: -30° to 25° C |
Charging temperature | 5° to 40° C |
Supported drones | DJI Mavic 3E DJI Mavic 3T DJI Mavic 3M |
GNSS | GPS + Galileo + GLONASS |
Dimensions | Antenna folded and control sticks not installed: 183.27×137.41×47.6 mm (length × width × height) Antenna unfolded and control sticks installed: 183.27×203.35×59.84 mm (length × width × height) |
Weight | approx. 680 g |
Model number | RM510B |
NOTES | |
Footnotes | 1. Standard aircraft weight (with battery, propellers, and microSD card). The actual product weight may vary due to batch materials and external factors. Use for reference purposes only. 2. Maximum speed in the EU cannot exceed 19 m/s. 3. Maximum wind resistance during takeoff and landing. 4. Data measured using DJI Mavic 3M in a windless environment while flying at sea level at a constant speed of 36 km/h until 0% power remained. For reference purposes only. Please pay attention to the Return to Home prompts in the DJI Pilot 2 app during flight. 5. Data measured using DJI Mavic 3M in a windless environment while hovering at sea level until 0% power remained. For reference purposes only. Please pay attention to the Return to Home prompts in the DJI Pilot 2 app during flight. 6. Data measured using DJI Mavic 3M in a windless environment while flying at sea level at a speed of 57.6 km/h until 0% power remained. For reference purposes only. Please pay attention to the Return to Home prompts in the DJI Pilot 2 app during flight. 7. In some countries, 5.1/5.8GHz frequencies are prohibited, or the 5.1GHz frequency is only allowed for indoor use. Please check local regulations and rules before use. 8. Data measured flying in an undisturbed outdoor environment free from interference. It shows the furthest communication range for one-way flights, with no return to home, in each standard. Please pay attention to the Return to Home prompts in the DJI Pilot 2 app during flight. 9. Data measured in an undisturbed environment with typical interference within various standards. Actual flight distance may vary and is for reference only. 10. DJI RC Plus will support more DJI drones in the future. |
